Krupp 75mm horse gun M. 1908





Rumenian designation :

Tunul de camp “Krupp”, calibrul 75 mm, model 1908

Calibre :

75mm L/30

Weight of the barrel :

350 kg

Weight of breech :

28 kg

Weight in action :

960 kg

Weight of the limber :

640 kg

Weight in marching order :

1600 kg

Weight of ammunition wagon :

1728 kg

Barrel length :

2250 m

Rifling

length :

1.741 m – 23.2 calibres

twist :

increasing, from 1 in 50 to 1 in 30 calibres

angle of twist :

from 3.6 to 6°

Barrel grooves

number :

28

depth :

0.75 mm

width :

5.92 mm

Shield thickness :

6 mm

Height of the line of fire :

990 mm

Cartridge

size :

75 x 280 x 90 R

weight :

8.5 kg

charge :

0.442 kg Rottweil smokeless powder

Shell

weight :

6.5 kg - charge: 0.14 kg Picric acid

fuze :

percussion - weight : 340 g

max. range :

6400 m (afterwards increased to 8000 m)

Shrapnel

weight :

6.32 kg - charge : 75 g of black powder

295 bullets x 11 g

fuze :

time and percussion - weight : 392 g

max. range :

5500 m (afterwards increased to 6000 m)

H.E.Shrapnel

weight :

6.5 kg - charge : 0.22 kg Trotyl

285 bullets x 9 g

fuze :

Ehrhardt Doppel Zünder C/1905

max. range :

5800 m

Muzzle velocity :

500 m/s

Elevation :

+ 16° / - 8°

Traversing angle :

4°

Recoil :

1370 mm

Height of the wheels :

1.30 m

Track :

1.48 m

Transport :

drawn by six horses

Ammunition :

gun limber - 24 shells, wagon limber - 24 shells, wagon body - 64 shells

12 ammunition wagons for every battery

Remarks :

Quick firing field gun for horse artillery batteries. The equipment was the same of the field gun M. 1903, but it was fitted for an independent line of sight. Romania bought 24 guns M. 1908 (6 batteries). Being lighter, this gun was used by horse artillery batteries.





75mm Krupp Horse Artillery guns in 1916
